CANOPY INSTALLATION GUIDE
(CCM-SBS-45410-40&50- CCM-SBS-70590-40&50)
PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION - To prevent personal injury or product damage only licensed electricians should install. Installation 1. Surface Mounted with J-box 1. Loosen the screw on side of the light, removing the bracket from canopy light by pulling it out slightly, just leaving the ring on bracket.
 2. Fix the bracket on J-box, and put the wire through the central hole for wiring
 3. Attach the Canopy light with bracket by putting the ring on clips again. Connect the black wire for Line, white for Neutral and Yellow-Green for Ground.
 4. Slide the Canopy lights into the bracket, and secure the screw on side of the light to prevent the light from sliding out from the bracket. Installation done.
 2. Pendent with 3/4 inch Conduit 1. Loosen the screw on side of the light, removing the bracket from Canopy light by pulling it slightly out, just leaving the ring on bracket. (See the Step 1 above)
 2. Connect the wires threaded from conduit and Canopy, Black wire for Line, White for Neutral and Yellow-Green for Ground.
 3. Screw the Conduit the hole on top of Canopy light
 3. Surface Mount 1. Remove the lens and metal plate by unscrewing the screws.
 2. Cut off the wires through from 3/4" hole and 3. Remove 1/2" plug from direction intent to feed conduit.
 3. Drill 4 holes on edge of fixture and fix it on the ceiling with using appropriate screws.
 4. Disconnect the wires came from 3/4" hole and connect the wires came from 1/2" conduit with power supply (White for Neutral Black for Line and Yellow Green-Green for Ground)
 5. Replace the metal plate and the lens, make sure no wires are pinched when replacing parts.
 Save the environment, your children and the planet
500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
[email protected] – www.ledradiant.com
5 YEAR WARRANTY POLICY
For Commercial LED Lamps and fixtures
• This warranty policy is valid only for products sold in The United States of America.
• Products have been purchased directly from a LEDRadiant (sales) organization. • Proof of purchase is available for inspection by LEDRadiant. • Products have been properly installed and operated in accordance with the manufacturer’s instructions. • More than 10% of the LED chips are not properly working. • A LEDRadiant representative will have access to the defective Products. • If the Products or other parts become suspect, the representative shall have the right to invite other manufacturers’ representatives to evaluate the lighting systems. • Shipping and Labor costs for installation of the Products are not covered under this warranty. This warranty is valid for order number: By LEDRadiant Save the environment, your children and the planet
500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
[email protected] – www.ledradiant.com |
- Product Description
-
- Additional Information
-
No
CANOPY INSTALLATION GUIDE(CCM-SBS-45410-40&50- CCM-SBS-70590-40&50)PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION
- To prevent personal injury or product damage only licensed electricians should install.
- To avoid electric shock or component damage disconnect power before attempting installation or servicing.
- This product must be installed in accordance with the national electric code (NEG) and all applicable federal, state and local electric codes and safety standards.
- Disconnect product and allow cooling prior to servicing.
- Any alteration or modification of this product is expressly forbidden as it may cause serious personal injury, death, property damage and/or product malfunction.
- To prevent product malfunction and/or electrical shock this product must be properly grounded.
- This luminaire is designed to operate in ambient temperatures ranging from -25•C to 40•C and to be horizontally mounted with the LEOs facing down.
Installation
1. Surface Mounted with J-box
1. Loosen the screw on side of the light, removing the bracket from canopy light by pulling it out slightly, just leaving the ring on bracket.
2. Fix the bracket on J-box, and put the wire through the central hole for wiring
3. Attach the Canopy light with bracket by putting the ring on clips again. Connect the black wire for Line, white for Neutral and Yellow-Green for Ground.
4. Slide the Canopy lights into the bracket, and secure the screw on side of the light to prevent the light from sliding out from the bracket. Installation done.
2. Pendent with 3/4 inch Conduit
1. Loosen the screw on side of the light, removing the bracket from Canopy light by pulling it slightly out, just leaving the ring on bracket. (See the Step 1 above)
2. Connect the wires threaded from conduit and Canopy, Black wire for Line, White for Neutral and Yellow-Green for Ground.
3. Screw the Conduit the hole on top of Canopy light
3. Surface Mount
1. Remove the lens and metal plate by unscrewing the screws.
2. Cut off the wires through from 3/4" hole and 3. Remove 1/2" plug from direction intent to feed conduit.
3. Drill 4 holes on edge of fixture and fix it on the ceiling with using appropriate screws.
4. Disconnect the wires came from 3/4" hole and connect the wires came from 1/2" conduit with power supply (White for Neutral Black for Line and Yellow Green-Green for Ground)
5. Replace the metal plate and the lens, make sure no wires are pinched when replacing parts.
Save the environment, your children and the planet500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
[email protected] – www.ledradiant.com
5 YEAR WARRANTY POLICYFor Commercial LED Lamps and fixtures
This document sets forth the warranty policy of the LEDRadiant organization (‘LEDRadiant’) from which you (‘Purchaser’) purchase your commercial LED Lamps .
This policy is applicable only to LEDRadiant (‘Products’) described in the Warranty Certificate extended to the Purchaser along with the correlated invoice or the Certificate in the website page for the product being questioned.
This warranty policy is subject to the provisions as set forth herein and is subject to the terms and conditions as attached to this document (‘Warranty Terms and Conditions’) .
This warranty policy only applies if referred to in a sales agreement between LEDRadiant and the Purchaser and it will replace the standard warranty clause provided in the LEDRadiant general terms and conditions of sale.
Warranty period
5 Year. The warranty period starts on the date the products are delivered.
By default, purchaser receives above mentioned ‘standard warranty’.
On request, an ‘extended warranty’ or ‘customized project warranty’ can be agreed upon after evaluation of the specific application conditions. Extended warranty cost will be calculated and applied to the order.
Purchaser shall not rely upon any other information or documentation.
Within the warranty period, LEDRadiant will replace any defective bulb or fixture with equal or updated working model in the same conditions or better.
Summary Warranty Terms and Conditions (non-exhaustive)• This warranty policy is valid only for products sold in The United States of America.
• Products have been purchased directly from a LEDRadiant (sales) organization.
• Proof of purchase is available for inspection by LEDRadiant.
• Products have been properly installed and operated in accordance with the manufacturer’s instructions.
• More than 10% of the LED chips are not properly working.
• A LEDRadiant representative will have access to the defective Products.
• If the Products or other parts become suspect, the representative shall have the right to invite other manufacturers’ representatives to evaluate the lighting systems.
• Shipping and Labor costs for installation of the Products are not covered under this warranty.
This warranty is valid for order number:
By LEDRadiant
Save the environment, your children and the planet500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
[email protected] – www.ledradiant.com - Product Tags
