SPECIFICATIONS:
SKU: HCC-ERS-05CI1-03



































Electrical:






                                Watts:5



                                Operating Voltage:120-277 VAC



                                Operating Temperature: 32° F to 104° F



                                Operating Humidity:20% to 90%RH



                                Power Factor (PF):>90%



                                Power Supply Efficiency:>90%









Photometric:






                                LED Luminous Flux (lm):XXX



                                Luminous Efficiency:0



                                CRI (ra):>72



                                Color Temperature (Kelvin):5000 K



                                Lens type:Polycarbonate



                                Expected Life: 70,000 hrs.



                                L70:50,000 hrs.



                                Beam Angle:180º









Mechanical:






                                IP Rating:IP66



                                Connector:Wired



                                Base Type: Hardwired



                                Heat Radiator:Anodized Aluminum



                                Color:Transparent



                                Product Size:10 1/4" x 17 1/8"




                                Package Size:12'' x 16'' x 16''



                                Unit Gross Weight: 10.0000 Lb









Certifications:






                                Safety Compliance:



                                EMI/RFI compliance:FCC



                                Energy Efficiency/Performance:



                                Environmental:RhOS































APPLICATIONS:

And more








                615 N 21st Avenue, Hollywood, FL 33020, United States of America - Tel: +1 (844)533-7230

[email protected] - www.ledradiant.com




Emergency Exit Sign – Red Light – Explosion Proof – Class I Division 1

Protect personnel and maintain code-compliant emergency egress with the Emergency Exit Sign – Red Light – Explosion Proof – Class I Division 1. Designed for hazardous environments where flammable gases, vapors, or combustible dust may be present, this rugged 5W LED explosion-proof exit sign provides dependable emergency illumination to help occupants safely evacuate during power failures or emergency situations. Engineered for industrial reliability, it delivers outstanding performance in some of the most demanding operating conditions.

Built for hazardous locations, this emergency exit sign is certified for Class I Division 1 environments, making it ideal for facilities where explosive atmospheres may exist under normal operating conditions. Its heavy-duty sealed enclosure is specifically engineered to withstand harsh industrial environments while protecting internal components from dust, moisture, corrosion, and other challenging conditions.

The fixture features bright red LED illumination, providing a highly visible EXIT indication that allows occupants to quickly identify emergency escape routes. LED technology delivers consistent brightness while consuming only 5 watts, offering exceptional energy efficiency, long service life, and minimal maintenance compared to traditional emergency exit signs.

One of its key advantages is its extended emergency backup time of up to 180 minutes, significantly exceeding the standard 90-minute emergency lighting requirement. This longer runtime provides additional security during prolonged power outages, ensuring exit pathways remain clearly visible when they are needed most.

Designed to operate on a universal AC 120–277V, 50/60Hz input, the fixture easily integrates into a wide variety of commercial and industrial electrical systems. Whether installed in a new hazardous facility or used to upgrade an existing emergency lighting system, it offers flexible installation and dependable operation.

Its compact, low-profile design combines durability with a professional industrial appearance while minimizing space requirements. The rugged explosion-proof housing is built for continuous operation, helping facility managers reduce maintenance costs while ensuring the exit sign remains ready for emergency use at all times.

This emergency exit sign is UL Certified and manufactured to comply with multiple industry safety standards, including UL844, UL1598, UL1598A, and UL913, providing confidence that it meets the strict performance and safety requirements for hazardous location lighting.

In addition to its Class I Division 1, Groups C and D rating, the fixture is also suitable for a broad range of hazardous environments, including:

• Class I, Division 2, Groups A, B, C & D
• Class II, Division 1, Groups E, F & G
• Class II, Division 2, Groups F & G
• Class III hazardous locations

These certifications make it a versatile solution for facilities that require explosion-proof emergency signage across multiple hazardous classifications.

The Emergency Exit Sign – Red Light – Explosion Proof – Class I Division 1 is an excellent choice for oil and gas facilities, petroleum refineries, chemical and petrochemical plants, battery rooms, pump stations, grain processing facilities, food manufacturing plants, marine terminals, offshore platforms, industrial warehouses, manufacturing plants, hazardous storage areas, stairwells, corridors, and emergency exits. Wherever hazardous materials are present, this fixture delivers reliable emergency guidance while helping facilities maintain compliance with industrial safety regulations.

Combining explosion-proof construction, 180-minute emergency operation, high-efficiency red LED technology, universal voltage compatibility, and industry-leading hazardous location certifications, this emergency exit sign provides the dependable performance required to protect workers and support safe evacuation in the most demanding industrial environments.

We invite you to browse our selection and do not hesitate to chat with us or call us to 844-533-7230 for any question regarding our LED products.
