                    SPECIFICATIONS:SKU: EMB-HH2-2590E-UL


















        Emergency driver for LED products






                        Electrical:



                                Watts:25


                                Operating Voltage:100-347 VAC


                                Operating Temperature: 32° F to 122° F


                                Operating Humidity:20% to 90%RH


                                Power Factor (PF):>98%


                                Power Supply Efficiency:>98%






                        Photometric:



                                LED Luminous Flux (lm):N/A


                                Luminous Efficiency:0


                                CRI (ra):>N/A


                                Color Temperature (Kelvin):n/a


                                Lens type:n/a


                                Expected Life: n/a hrs.


                                L70:n/a hrs.


                                Beam Angle:n/aº






                        Mechanical:



                                IP Rating:IP40


                                Connector:Wired


                                Base Type: Hardwired


                                Heat Radiator:Sheet Metal


                                Color:White


                                Product Size:12.24" x 2.59" x 1.53"



                                Package Size:22'' x 18'' x 13''


                                Unit Gross Weight: 4.0000 Lb






                        Certifications:



                                Safety Compliance:


                                EMI/RFI compliance:FCC


                                Energy Efficiency/Performance:


                                Environmental:RhOS
























                    APPLICATIONS:
                    And more





                615 N 21st Avenue, Hollywood, FL 33020, United States of America - Tel: +1 (844)533-7230
                [email protected] - www.ledradiant.com











LED Emergency Driver – 25W, Field Installable, UL Listed (100-347VAC)

Be ready for anything with the 25W LED Emergency Driver, a dependable backup power solution for your LED lighting systems. Designed for field or factory installation, it supports 100-347VAC input and works seamlessly with LED fixtures from 9W up to 350W.

Perfect for commercial spaces, warehouses, schools, and industrial environments, this emergency driver ensures your lights stay on for up to 90 minutes during an outage—giving you time to respond safely.

Highlights:

UL certified and Title 20 compliant for safety and energy standards.
Compatible with NFPA 101 Life Safety Code regulations.
Includes a dual-function test button and indicator light for easy checks.
Offers automatic monthly and yearly testing.
Optional remote test activation.
Advanced built-in protections: overcharging, deep discharge, overload, short-circuit, and open load.

This unit delivers a constant 25W output during emergencies and is powered by a reliable lithium battery that recharges in under 24 hours. With a working temperature range of 0–50°C (32–122°F), it’s ready for most indoor environments.

Key Details:

Power Input: Max 8W
Input Current: Max 0.1A
Power Factor: 0.6 at 100V, 0.5 at 347V
Emergency Output: 145VDC
Battery Type: Lithium
Emergency Operation Time: 90 minutes
Warranty: 5 years

For luminaires drawing more than 25W, make sure to connect the 0-10V or 1-10V dimming wires for proper emergency performance.

Whether you're retrofitting or installing from scratch, this driver gives you peace of mind and keeps your building prepared when the lights go out.

Smart. Safe. Built to perform when you need it most.
